Liteweight 02-23-2015 03:27 PM

Re: Original hemi dart information

2 Attachment(s)
I was just notified of this. Wishing Stewart all the best. One of the great ones with the personality to match

http://board.moparts.org/ubbthreads/...gonew=1#UNREAD


liteweight

Charlie A 02-23-2015 06:39 PM

Re: Original hemi dart information

Quote:

Originally Posted by Liteweight (Post 462857)
I was just notified of this. Wishing Stewart all the best. One of the great ones with the personality to match

http://board.moparts.org/ubbthreads/...gonew=1#UNREAD


liteweight


http://classracer.com/classforum/att...1&d=1424719610http://classracer.com/classforum/att...0&d=1424719537

tommy d 03-02-2015 10:03 PM

Re: Original hemi dart information

1 Attachment(s)
facebook

Doug Walker 03-09-2015 08:04 PM

Re: Original hemi dart information

2 Attachment(s)
I found an envelope of photos this past week with a few Hemi Dart pictures.
Just had them scanned for your viewing pleasure.

Summer of 1973 or 1974 a friend was going to the US Nationals and my older brother asked if a few photos could be taken of the quarter panels of a few original Hurst prepped Hemi Darts. The white Dart appears to be an original from the Hurst facility. Do not know what to think of the "Hurley Automotive" Dart as the forward edge of the wheel opening has a curved shape to it.

Original photos by Joe Archer from Omaha, Nebraska.

Doug Walker 03-09-2015 08:10 PM

Re: Original hemi dart information

1 Attachment(s)
Here is another image of the other side of the "Hurley Automotive" Hemi Dart.

Charlie A 03-09-2015 08:14 PM

Re: Original hemi dart information

Cool pics! Love the old Motor Wheel Spyder wheels!

http://classracer.com/classforum/att...4&d=1425945843
http://classracer.com/classforum/att...5&d=1425945843
http://classracer.com/classforum/att...6&d=1425946203

marfen 03-10-2015 10:32 AM

Re: Original hemi dart information

Quote:

Originally Posted by Doug Walker (Post 464306)
I found an envelope of photos this past week with a few Hemi Dart pictures.
Just had them scanned for your viewing pleasure.

Summer of 1973 or 1974 a friend was going to the US Nationals and my older brother asked if a few photos could be taken of the quarter panels of a few original Hurst prepped Hemi Darts. The white Dart appears to be an original from the Hurst facility. Do not know what to think of the "Hurley Automotive" Dart as the forward edge of the wheel opening has a curved shape to it.

Original photos by Joe Archer from Omaha, Nebraska.


Looks like the leading edge rear wheel opening on the Hurley car retains the original Hurst profile while the white car has the common modification of trimming the fender/rocker to gain more tire clearance once you go to taller/high growth slicks. The only other way was to move the diff back on the leaf spring perches.

a990hemi 03-10-2015 10:40 AM

Re: Original hemi dart information

Here's a template which was made from a documented original wheel opening.


http://i705.photobucket.com/albums/w...psj1lvxru0.jpg

Liteweight 03-10-2015 11:28 AM

Re: Original hemi dart information

Welcome here Doug. Great pictures you found. Thanx for sharing. Do you have more?

About the rear openings. There are probably not 2 LO23 Darts out there, even new, that have the same opening shape. They were modified by hand, torch, & hammer at Hurst. I'd even go to the extent the DS was different to the PS.

Below is a pic of mine. They've really been opened on the forward side, but still retain the original outer tubs. Available tire diameter started dictating opening size. There weren't tires available of size till the early 70's.

Anyone recognize the ID on that white Dart?

liteweight


http://i1115.photobucket.com/albums/...ps6fb6950f.jpg

Liteweight 03-10-2015 11:31 AM

Re: Original hemi dart information

Quote:

Originally Posted by a990hemi (Post 464392)
Here's a template which was made from a documented original wheel opening.


http://i705.photobucket.com/albums/w...psj1lvxru0.jpg


Steve
That forward opening looks WAY to much for a Hurst mod. it looks like it goes past the forward section of the wheel tub. Hurst only modified to the stock front lower section of the tub.

liteweight
